Description:
1. Dual Outputs For Smart Load Management
2. Maximum Pv Input Current 27a
3. Wide Pv Input Voltage Range 60vdc~450vdc
4. Detachable Lcd Control Module With Various Communications
5. Integrated Wifi Interface With Mobile App
6. Supports Usb On-the-go Function
7. Reserved Communication Port (rs-485, Can-bus Or Rs-232) For Bms
8. Battery Equalization Extends Lifecycle
9. Battery Independency
10. User-friendly Lcd Operation
11. Replaceable Fan Design
| Technical Specification | VM IV TWIN TECH series | |
|---|---|---|
| Rated Power | 6000VA/6000W | |
| AC INPUT | ||
| AC Voltage | 230VAC | |
| Voltage Range | 170-280VAC (For Personal Computers); 90-280 VAC (For Home Appliance) | |
| Frequency Range | 50/60Hz (Auto sensing) | |
| AC OUTPUT | ||
| Surge Power | 12000VA | |
| AC Voltage Regulation (Battery Mode) | 230VAC ±5% | |
| Efficiency (Peak) | 93% | |
| Transfer Time | 10ms (For Personal Computers); 20 (For Home Appliance) | |
| BATTERY | ||
| Battery Voltage | 48VDC | |
| Floating Charge Voltage | 54VDC | |
| Overcharge Protection | 63VDC | |
| Battery Type | Lithium/Lead-Acid | |
| SOLAR CHARGER & AC CHARGER | ||
| Maximum PV Array Open Circuit Voltage | 500VDC | |
| Maximum PV Array Power | PV 8500 | |
| MPPT Range (V) | 60~450VDC | |
| Maximum Input Current | 27A | |
| MPPT Tracker/String | 1/1 | |
| Maximum Solar Charge Current | 120A | |
| Maximum AC Charge Current | 100A | |
| Maximum Charge Current | 120A | |
| Protection & Feature | ||
| AC Overload Protection | Yes | |
| Over Temperature Protection | Yes | |
| Smart Parallel Operation | No | |
| PHYSICAL PARAMETERS | ||
| Operation Temperature | -10°C~50°C | |
| Dimension DxWxH (mm) | 115 x 300 435 | |
| Net Weight (kg) | 10 | |
| DISPLAY AND COMMUNICATION | ||
| Display | Touch buttons | |
| Standard | Standard: RS232; CAN/RS485; Optional: Wi-Fi/Bluetooth | |
| Safety Standard | EN/IEC62109-1,EN/IEC62109-2 | |
